Capacitive Fingerprint Sensor SEN0348 (Without Wire)

Specifications: Operating Voltage: 3.3V Operating Current: <60mA Sleep Mode Current: <10uA(Disconnect VIN pin from 3.3V to enter sleep mode) Communication Method: UART Storage: 80 fingerprints 1 : 1 verification time: 300~400ms Pixel Resolution: 508dpi Number of Pixels: 160×160 Fingerprint Detection Area: 8.0mm x 8.0mm Working Environment: ‐40‐60℃/<RH 90% Dimension: diameter 21mm/height 6mm
