Heltecbms bms 48v 16s lifepo4/Lipo 16s 60v with balance 30a 50a 80a 100a 120a 160a 200a 250a 300a 350a board for inverter bms

16S 30A 50A 3.7V Same Port Size: 72*55*8mm Overcharge protection: 4.25v±0.25v Charging recovery: 4.2V±0.25v Over-discharge protection: 2.8v±0.25v Discharge recovery: 3.0v±0.25v Maximum continuous current: 30A/50A Peak Current: 90A/150A Balance current: 80 mA Balanced starting voltage: 4.22v±0.25v Charging recovery Self-consumption: ≤35uA 16S 30A 50A 3.2V Same Port Size: 72*55*8mm Overcharge protection: 3.65v±0.25v Charging recovery: 3.55V±0.25v Over-discharge protection: 2.35v±0.25v Discharge recovery: 2.55v±0.25v Maximum continuous current: 30A/50A Peak Current: 30A/150A Balance current: 80 mA Balanced starting voltage: 3.405v±0.25v Charging recovery Self-consumption: ≤35uA   16S 80A 120A 160A 3.7V Same Port Size:115*66*8/12mm Overcharge protection: 4.25v±0.25v Charging recovery: 4.2V±0.25v Over-discharge protection: 2.8v±0.25v Discharge recovery: 3.0v±0.25v Maximum continuous current: 80A/120A/160A Peak Current: 240A/360A/480A Balance current: 100 mA Balanced starting voltage: 4.22v±0.25v Charging recovery Self-consumption: ≤35uA 16S 80A 120A 160A 3.2V Same Port Size: 115×66×18 Overcharge protection voltage: 3.65V Charge protection release voltage:3.55V Over-discharge protection voltage: 2.35V Discharge release voltage :2.55V Balance start Volatge:3.4V Abnormal high voltage protection: yes Temperature protection: Optional Maximal continuous current: 60A/80A/120/160A Peak current :180A/240A/360A/480A Balanced current:100Ma   16S 200A 350A 3.7V Same Port Size: 190*97*14mm Overcharge protection: 4.25v±0.25v Charging recovery: 4.2V Over-discharge protection: 2.8v±0.25v Discharge recovery: 3.0v Max continuous current: 160A Max Charge Current :200A/350A Peak Current: 600A/1050A Balance current: 100 mA Balanced starting voltage: 4.22v±0.25v Charging recovery 16S 200A 350A 3.2V Same Port Size: 190*97*14mm Overcharge protection voltage: 3.65V Charge protection release voltage:3.55V Over-discharge protection voltage: 2.35V Discharge release voltage :2.55V Balance start Volatge:3.4V Abnormal high voltage protection: yes Temperature protection: Optional Maximal continuous current: 200A/350A Peak current :600A/1050A Balanced current:100Ma   16S 250A 3.7V Same Port Size: 150*80*14mm Overcharge protection: 4.25v±0.25v Charging recovery: 4.2V Over-discharge protection: 2.8v±0.25v Discharge recovery: 3.0v Max continuous current:250A Max Charge Current :750A Peak Current: 240A/360A/480A Balance current: 100 mA Balanced starting voltage: 4.22v±0.25v Charging recovery 16S 250A 3.2V Same Port Size: 150*80*14mm Overcharge protection voltage: 3.65V Charge protection release voltage:3.55V Over-discharge protection voltage: 2.35V Discharge release voltage :2.55V Balance start Volatge:3.4V Abnormal high voltage protection: yes Temperature protection: Optional Maximal continuous current: 250A Peak current :750A Balanced current:100Ma   Sugget to conenct with Silicone cable with copper nose Note: All holes need to be connect as pictures shows    Package include
