Heltec 8-Channel Hybrid Battery Tester: 2-20V Input, 5A Max Current (Charge-Discharge & Balancing)

Heltec Energy HT-ED05AC8V20 Hybrid Vehicle Battery Tester Professional 8-Channel Charge-Discharge & Equalization Repair Instrument Key Features 8 Independent Channels Channels work without mutual interference; each supports separate parameter setting, independent startup, and compatibility with different batteries. Full-channel isolation test: Directly test all cells in a battery pack without disconnecting connections (modular design enables series detection). PC-Controlled Operation Connect to a Windows (XP ) computer (1600×900 resolution) for centralized parameter setting & real-time monitoring. One computer can control multiple devices (serial connection, custom equipment required for cascading). Comprehensive Battery CompatibilitySupports Toyota hybrid models (Corolla, Camry, Prius) & battery types: Nickel-metal hydride (NiMH) batteries 04/06/08/12 hybrid battery cells (2-20V voltage range) Core Functions Charge/Discharge0.2-5A current range; 5-18V termination voltage; 0.01-99999.9AH capacity test range. Intelligent EqualizationSet target voltage; automatically levels cell voltages to resolve uneven charging issues. Internal Resistance TestinLoads max current on startup to display internal resistance (nΩ), enabling quick battery condition assessment. Reliable Performance Power Specs: AC220V input; 25W (standby/discharge), 550W (full-load charging). Safety: 1000V AC channel-to-channel pressure resistance (2min no abnormality). Cooling: Multi-fan intelligent temperature control (real-time temp monitoring; high-temp alarm/shutdown). Product Parameters Model HT-ED05AC8V20 Input Voltage AC220V 50HZ±15% Input Current AC 0.1-2.5A (8 channels) Accuracy 0.01-0.05V / 0.05A / 0.1AH Dimensions 495×235×110mm Application Scenarios Ideal for auto repair shops, battery maintenance centers, and hybrid vehicle service providers — efficiently test, balance, and repair hybrid battery packs to restore performance.
